Sirius

Performance

Cruise 116 KTAS (135 KTAS ROTAX 916)
Stall Vso 35 KCAS
Stall Vs1 40 KCAS
Maneuvering speed 108 KIAS
Never exceed speed 138 KIAS
Best rate of climb speed Vy 65 KIAS
Best angle of climb Vx 59 KIAS
Best climb rate 1200 ft/min (1800 ft/min (ROTAX 916)
Take-off roll distance (ground roll) 350 ft
Take-off distance (50ft obstacle) 1400 ft
Landing distance 460 ft
Landing distance (50ft obstacle) 1050 ft
Load factor +4/-2g
Fuel consumption 3.8 – 7.2 gal/hr depending on engine selection
Range 750 miles

Dimensions

Length 22.15 ft
Height 7.38 ft
Wing span 30.8 ft
Wing area 121.2 ft2
Wing loading 10.89 lb/ft2 (MTOW 1320 lbs)
Horizontal tail width 9.85 ft
Cabin width 45 in

Weight

Empty weight 820 – 870 lbs
Gross weight 1320 lbs
Fuel tank Capacity 34.4 gallon
Luggage weight 55 lbs
Luggage compartment size 6.5 cubic ft

Engine/Propeller

DUC Swirl
DUC Flash
DUC Tiger constant speed
TL Predator constant speed
Rotax 912ULS/iS
Rotax 914 iS
Rotax 916iS
Turbotech Turboprop TP-R90 (140 HP)

Equipment

VFR
Garmin Dual GDU 460 G3X touch display
Garmin GDU 450 G3X single display
Garmin GMC 507 auto pilot with GARMIN GSA smart servos
Garmin GTR 205 panel mount radio
Garmin G5
Garmin Gi 275
Garmin GTR 20 remote radio
ELT Kannad
Bose Lemo connectors
Dash lighting for night flight
Infinity grips for both controls
TCW 6amp/hr backup battery

IFR
Garmin GNX 375
Garmin GNC 355
Garmin GTN 650Xi
Garmin GTN 750Xi
Garmin GNC 215 Nav/Com
Garmin GMA 245 and 245R
Garmin 2nd GSU-25C
Garmin GAP 26 AOA probe heated

Airframe Equipment/Safety

Stratos Magnum Ballistic Parachute Recovery System (Magnum 601 750kg)
Steerable nose wheel
Hydraulic differential disc brakes with brake pedals for both pilot and co-pilot
Parking brake
Locking canopy
Locking gas caps
Tinted canopy and protective cover available
Elevator trim
Electric flap controls
Rear luggage compartment (size 6.5 cubic ft)
Four point seat belts
Wheel fairings
Cabin heat
Front canopy ventilation
Anticollision lights
Nav lights
Landing lights in wings
Dash lighting for night flight
Leather glare-shield
Center console compartment for maps and storage
Tail skid

Comfortable, versatile, forgiving

Just like the name suggests, the Sirius is a luxurious, versatile aircraft making it a standout in the light sport category. Per Greek astronomy, Sirius means the brightest star in the night sky. This aircraft has lived up to its name with an undisputed reputation for reliability, ease of handling, predictability, and comfort.

In production for 25 years with over 300 deliveries worldwide, this custom-built E/AB MOSAIC-ready aircraft has proven its worth with flight schools, corporate executives, and family-fliers. The clean, flowing lines of the Sirius evoke a profile of a modern aircraft that looks impressive in the air and on the runway.

The cockpit design of the Sirius addresses pilots and crew of all shapes and sizes. The 2-seat high-wing has easy access and provides ample space for “well-built” pilots and crew with a 45” cockpit. The large doors open upwards and are held in place by hydraulic struts making entry and exit into the aircraft easy for those with reduced flexibility. Even individuals up to 6’6” will have plenty of headroom. The bottom edge of the door is intentionally designed to be located below seat-level making entry easy for shorter pilots.

The TL engineers paid great attention to the design and aerodynamics of the carbon-fiber composite aircraft which allow it to perform perfectly at low speed thanks to the large wing area and electric flaps. At high speeds, the aerodynamic cleanness of the aircraft offers impressive performance with low fuel consumption. From just above the stall through fast cruise, the performance will surprise you. Even strong crosswind landings are no challenge for the Sirius.

Engine options for the Sirius include Rotax (912ULS/iS, 914iS, 916iS) and Turbotech (Turboprop TP-R90). Planning your destinations will be exciting with a 750-mile range.

The Sirius is configured with the latest in glass panel technology including the Garmin Dual GDU 460 G3X touch display and Garmin GDU 450 G3X single display and the GARMIN Autopilot with control panel GMC 507. A well-appointed leather interior and heated leather seats will envelop you during chilly flights. All the controls are well-arranged for an easy scan and located within easy reach. The steering yokes with PTT and adjustable rudder pedals are provided for both pilot and copilot.

Here are additional features of the Sirius.

Ever considered an amphibian? The Sirius can be outfitted with floats.
Looking for an aero-towing aircraft? Sirius’ aerodynamics, large wings and effective flaps make it capable of towing gliders.
If aerial photography interests you, the cabin door can be opened in flight or easily removed on the ground.

Additional options include but are not limited to IFR capability, Oxygen, and design of custom paint scheme.

Every Sirius is custom ordered, built, and delivered with the same passion and commitment to quality as the first TL aircraft over 35 years ago.
